系統版本:CentOS6.5DRBD版本:DRBD-8.4.3node1: 192.168.7.88(drbd1)node2: 192.168.7.89 (drbd2)(node1)為僅主節點配置(node2)為僅從節點配置(node1,node2)為主從節點共同配置二、准備環境:(node1,node2)
1.關閉iptables和SELINUX,避免安裝過程中報錯
service iptables stop //關閉iptablessetenforcing 0 //暫時關閉selinuxsed -i 's/SELINUX=enforcing/SELINUX=disabled/' /etc/sysconfig/selinux //永久關閉selinux
2.設置hosts文件
vi /etc/hosts127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4::1 localhost localhost.localdomain localhost6 localhost6.localdomain6192.168.7.88 drbd1192.168.7.89 drbd2
3.在兩台虛擬機上添加一塊2G硬盤sdb作為DRBD,分別分區為sdb1,大小1G,並在本地系統創建/data目錄,不做掛載操作。
fdisk /dev/sdb----------------n-p-1-回車-"+1G"-wq----------------mkdir /data
4.時間同步:
ntpdate -u asia.pool.ntp.org三、DRBD的安裝部署
1.安裝依賴包:(node1,node2)
yum install gcc gcc-c++ make glibc flex kernel-devel kernel-headers
2.安裝DRBD:(node1,node2)
wget http://oss.linbit.com/drbd/8.4/drbd-8.4.3.tar.gztar zxvf drbd-8.4.3.tar.gzcd drbd-8.4.3./configure --prefix=/usr/local/drbd --with-kmmake && make installmkdir -p /usr/local/drbd/var/run/drbdcp /usr/local/drbd/etc/rc.d/init.d/drbd /etc/rc.d/init.dchkconfig --add drbdchkconfig drbd on加載DRBD模塊:modprobe drbd查看DRBD模塊是否加載到內核:lsmod |grep drbd四、DRBD的配置
1.參數配置:(node1,node2)
vim /usr/local/drbd/etc/drbd.conf清空裡面的配置,添加如下配置:resource r0{protocol C;startup { wfc-timeout 0; degr-wfc-timeout 120;}disk { on-io-error detach;}net{ timeout 60; connect-int 10; ping-int 10; max-buffers 2048; max-epoch-size 2048;}syncer { rate 30M;}on drbd1.example.com{ device /dev/drbd0; disk /dev/sdb1; address 192.168.7.88:7788; meta-disk internal;}on drbd2.example.com{ device /dev/drbd0; disk /dev/sdb1; address 192.168.7.89:7788; meta-disk internal;}}
2.創建DRBD設備並激活r0資源:(node1,node2)
mknod /dev/drbd0 b 147 0drbdadm create-md r0等待片刻,顯示success表示drbd塊創建成功----------------Writing meta data...initializing activity logNOT initializing bitmapNew drbd meta data block successfully created. --== Creating metadata ==--As with nodes, we count the total number of devices mirrored by DRBDat http://usage.drbd.org.The counter works anonymously. It creates a random number to identifythe device and sends that random number, along with the kernel andDRBD version, to usage.drbd.org.http://usage.drbd.org/cgi-bin/insert_usage.pl?nu=716310175600466686&ru=15741444353112217792&rs=1085704704* If you wish to opt out entirely, simply enter 'no'.* To continue, just press [RETURN] //出現[RETURN]按回車success----------------再次輸入該命令:# drbdadm create-md r0成功激活r0----------------[need to type 'yes' to confirm] yesWriting meta data...initializing activity logNOT initializing bitmapNew drbd meta data block successfully created.
3.啟動DRBD服務:(node1,node2)
service drbd start
注:需要主從共同啟動方能生效
4.查看狀態:(node1,node2)
cat /proc/drbdversion: 8.4.3 (api:1/proto:86-101)GIT-hash: 89a294209144b68adb3ee85a73221f964d3ee515 build by [email protected],2013-05-27 20:45:190: cs:Connected ro:Secondary/Secondary ds:Inconsistent/Inconsistent C r----- ns:0 nr:0 dw:0 dr:0 al:0 bm:0 lo:0 pe:0 ua:0 ap:0 ep:1 wo:f oos:1060184或者service drbd statusdrbd driver loaded OK; device status:version: 8.4.3 (api:1/proto:86-101)GIT-hash: 89a294209144b68adb3ee85a73221f964d3ee515 build by [email protected],2013-05-27 20:45:19m:res cs ro ds p mounted fstype0:r0 Connected Secondary/Secondary Inconsistent/Inconsistent C
注:這裡ro:Secondary/Secondary表示兩台主機的狀態都是備機狀態,ds是磁盤狀態,顯示的狀態內容為“不一致”,這是因為DRBD無法判斷哪一方為主機,應以哪一方的磁盤數據作為標准。
5.將drbd1主機配置為主節點:(node1)
drbdsetup /dev/drbd0 primary --force
分別查看主從DRBD狀態:
(node1)service drbd statusdrbd driver loaded OK; device status:version: 8.4.3 (api:1/proto:86-101)GIT-hash: 89a294209144b68adb3ee85a73221f964d3ee515 build by [email protected],2013-05-27 20:45:19m:res cs ro ds p mounted fstype0:r0 Connected Primary/Secondary UpToDate/UpToDate C(node2)service drbd statusdrbd driver loaded OK; device status:version: 8.4.3 (api:1/proto:86-101)GIT-hash: 89a294209144b68adb3ee85a73221f964d3ee515 build by [email protected],2013-05-27 20:49:06m:res cs ro ds p mounted fstype0:r0 Connected Secondary/PrimaryUpToDate/UpToDateC
注:ro在主從服務器上分別顯示 Primary/Secondary和Secondary/Primary ds顯示UpToDate/UpToDate表示主從配置成功。
6.掛載DRBD:(node1)
從剛才的狀態上看到mounted和fstype參數為空,所以我們這步開始掛載DRBD到系統目錄mkfs.ext4 /dev/drbd0mount /dev/drbd0 /data注:Secondary節點上不允許對DRBD設備進行任何操作,包括只讀,所有的讀寫操作只能在Primary節點上進行,只有當Primary節點掛掉時,Secondary節點才能提升為Primary節點繼續工作。五、模擬故障
(node1)
cd /datatouch 1 2 3 4 5cd ..umount /datadrbdsetup /dev/drbd0 secondary
注:這裡實際生產環境若DRBD1宕機,在DRBD2狀態信息中ro的值會顯示為Secondary/Unknown,只需要進行DRBD提權操作即可。
(node2)
drbdsetup /dev/drbd0 primarymount /dev/drbd0 /datacd /datatouch 6 7 8 9 10ls--------------1 10 2 3 4 5 6 7 8 9 lost+found
查看(node1)(node2)DRBD狀態:
(node2)service drbd statusdrbd driver loaded OK; device status:version: 8.4.3 (api:1/proto:86-101)GIT-hash: 89a294209144b68adb3ee85a73221f964d3ee515 build by [email protected],2013-05-27 20:49:06m:res cs ro ds p mounted fstype0:r0 Connected Primary/Secondary UpToDate/UpToDate C /data ext4(node1)service drbd statusdrbd driver loaded OK; device status:version: 8.4.3 (api:1/proto:86-101)GIT-hash: 89a294209144b68adb3ee85a73221f964d3ee515 build by [email protected],2013-05-27 20:45:19m:res cs ro ds p mounted fstype0:r0 Connected Secondary/Primary UpToDate/UpToDate C
